50x210mm Woody Short Leg Joist Hanger

50x210mm Woody Short Leg Joist Hanger
50x210mm Woody Short Leg Joist Hanger
Price: £0.78 (£0.94 inc VAT)
  • Product Code: A1-5030
  • Delivery Time: In stock, 1-2 days
  • Brand: TECO
  • Model and Size: SHORTLEG - 50x210
  • Weight: 154.00g
Show other sizes

50x210mm Woody Short Leg Joist Hanger

Width: 50mm
Height: 210mm
Thickness: 0.8mm
Weight: 154g

50mm x 210mm Woody Short Leg Joist Hanger is produced from 1mm thick pre-galvanised mild steel produced in accordance to  EN BS 10327:2004 DX51D+Z275.  It has a shortened leg, and with a 50mm joist bearing.  The hanger includes a base tag which can significantly contribute to faster and more accurate installation. The base tag would avoid unnecessary rotation. Long term safe working load = 3.96 kN.


FIXING INSTRUCTIONS for 50x210mm Woody Short Leg Joist Hanger

  • All holes should be nailed using 30 x 3.75 square twist nails or equivalent, for stainless steel products use 30 x 3.75 stainless steel annular ring shank nails.
  • Always ensure that compatible corrosion resistant fixings are used, i.e. do not use galvanised fixings with stainless steel products or vice versa.
  • Tag on the base of the hanger to help avoid rotation and aid fast, accurate location. The tag can be bent if not required.

SPECIFICATION

  • Joist bearing 50mm.
  • Also available in Stainless Steel.
  • Tested by Ceram Research.
